Multidirectional Converters

Sierra 25 48/230-277

The world’s first fully bi-directional
converter for small or large systems.
Back to
AC In
230, 240 & 277 Vac
DC In
48 Vdc
AC Out
230, 240 & 277 Vac
DC Out
48 Vdc
Power
2.7 kW 3 kVA
Up to
2 MW 2.2 MVA

What's in it for you?

Sierra 25 – 48/230-277 can be used as a UPS to secure AC & DC loads and charge the batteries. The 3 all bidirectional ports allow for multiple innovative applications such as grid reinjection, peak shavings, phase balancing or energy sharing through DC distribution, among many others.

By using several modules, we can offer solutions for three-phase (3x400Vac + N) infrastructures.

The module can be integrated in small or large cabinets to reach up to 2 MW. With our new Inview S monitoring, you can benefit from a unique experience.

The total output power per module is 2.7 kW, limited to 2.4 kW for each AC or DC port.

Key Features

  • Secure AC & DC loads;
  • Many innovative applications;
  • Compatible with Inview S;
  • Modularity: from 2.7 kW to 2 MW;
  • From small to large systems.

Technical Data

In/Out: DC voltage (range) 48 Vdc (32 – 63)
In/Out: AC voltage (range) 230, 240 & 277 Vac
(150 – 293 Vac)
Output power 3 kVA / 2.7 kW
Efficiency: DC/AC 93.7%
Efficiency: AC/AC 96%
Temperature -40°C to 65°C
Dimension 2U x 103 mm x 435 mm
Part number T721D30201
